CABINET-BATTERY  51.2V920AH  47.10KWH

Can support 4 cabinets battery in parallel.

Adapted to over 90% of global inverter brands

Battery parameters

Cell pack basic parameter

Pack Nominal Voltage/V

51.2V

Max Charge Voltage/V

3.65V

Cell Nominal Capacity/Ah

230Ah * 4

Battery Pack Energy/KWh

47.10KWh

Cell Max Discharge Rate/C

1C

Cell Max Charge Rate/C

0.5C

Cell In Series

16

Cell In Parallel

1

Battery Pack Method

Laser welding

DOD

80%

Cycle Life

7000 times

Warranty

7 years

Battery Parameter

LED Display

7"Color Capacitive Touch Screen

BMS Type

Software RS485/CAN

Operating Voltage Range/V

44V-58.4V

Continuous Current/A

160A

Charge voltage(MAX)/V

58.4V

Type Current/A

200A

Continuous Current(MAX)/A

200A

Over Voltage/V

44V

Maximum Output Power/KW

40 KW

Battery Dimension/MM

1335*580*558

Net Weight/KG

480KG

Charge/Discharge Port

M8 Bolt

Temperature Protection

Discharging:-15-70℃；Charging:0-60℃
